Eaton FDC3035 3 Pole Circuit Breaker
Specifications :
• Series: C
• Amperage: 35
• Poles: 3
• Mounting Type: Panel
• MPN: FDC3035
• Voltage: 600VAC, 250VDC
• Phase: 3
• Frame Type: FD
• Connection Type: Bolt-On
• Functions: Long Time and Instantaneous Trip
• Protection: Thermal Magnetic
• Application: Reverse Feed
• Terminal Connection: Load Side Lug
• Temperature Rating: 40°C
• Action: Blow Open
• Body Material: Glass Polyester
• Interrupting Rating: 100kAIC at 480VAC, 200kAIC at 240VAC
• Size: 6"H x 4.13"W x 3.38"D
• Approval: UL, IEEE
