New EHD2025 Eaton EHD2025 2 Pole Circuit Breaker

Eaton EHD2025 2 Pole Circuit Breaker

Specifications :

• Series: EHD

• Amperage: 25

• Poles: 2

• Mounting Type: Din Rail, Panel

• MPN: EHD2025

• Voltage: 480VAC, 250VDC

• Phase: 1

• Frame Type: EHD

• Connection Type: Bolt-On

• Circuit Breaker Type: Standard

• Functions: LI - Long Time and Instantaneous

• Protection: Thermal Magnetic

• For Use With: Motor Control Centers

• Terminal Connection: Load Side Lug

• Temperature Rating: -4 to 158 °F

• Actuator Type: Toggle

• Min Wire Size: 14 AWG

• Max Wire Size: 1/0 AWG

• Interrupting Rating: 18kAIC at 240VAC, 14kAIC at 480VAC

• Size: 6"H x 2.75"W x 3.38"D

• Approval: UL, CSA, IEC

• Standards: RoHS
