New FAZ-C50/3 Eaton FAZ-C50/3 3 Pole Circuit Breaker

Eaton FAZ-C50/3 3 Pole Circuit Breaker

Specifications :

• Series: FAZ

• Amperage: 50

• Poles: 3

• Mounting Type: Din Rail

• MPN: FAZ-C50/3

• Voltage: 277/480VAC, 96VDC

• Phase: 3

• Frame Type: FAZ

• Connection Type: Feed-Thru

• Functions: LI - Long Time and Instantaneous

• Protection: Thermal Magnetic

• Application: Appliances and Some Motors, Business Equipment, Control Circuits and Coils, PLC Wiring, Industrial, Lighting, Pilot Devices, Small Transformers and Power Supplies

• Terminal Connection: Line and Load

• Temperature Rating: -40 to 75°C

• Wire Gauge: 18 to 4 AWG, 18 to 8 AWG

• Actuator Type: Toggle

• Min Wire Size: 18 AWG

• Max Wire Size: 4 AWG

• Body Material: Nylon

• Interrupting Rating: 15kAIC

• Size: 2.07"H x 2"W x 2.07"D

• Approval: UL, CSA, IEC, CE, VDE

• Standards: RoHS
