New CCH3175 Eaton CCH3175 3 Pole Circuit Breaker
Eaton CCH3175 3 Pole Circuit Breaker
Specifications :
• Series: CCH
• Amperage: 175
• Poles: 3
• MPN: CCH3175
• Voltage: 240VAC
• Phase: 3
• Frame Type: CC
• Connection Type: Feed-Thru
• Functions: Long Time and Instantaneous Trip
• Protection: Thermal Magnetic
• Circuit Breaker Type: CC
• For Use With: Type ECC Unit Enclosures
• Application: Generation - Renewable Energy - Alternative Energy Other Data Centers - IT Space: CI and Hyper Converged Marine Vessels and Equipment - Other Generation - Conventional Energy - Residential Bldgs and Facilities - Other
• Terminal Connection: Line and Load Side Lug
• Temperature Rating: 40°C
• Wire Gauge: #2/0 AWG to 300KCmil CU/AL
• Interrupting Rating: 100kAIC
• Size: 5.2"H x 5.7"W x 7.7"D
• Approval: UL
