SEHA24AT0030 Recertified General Electric Circuit Breaker

General Electric SEHA24AT0030 2 Pole Circuit Breaker

Specifications :

• Series: Spectra RMS

• Amperage: 30

• Poles: 2

• Mounting Type: Panel

• Voltage: 480VAC

• Phase: 1

• Frame Type: E

• Connection Type: Bolt-On

• Functions: Long Time, Short Time and Instantaneous Trip

• Protection: Solid State

• Application: Reverse Fed

• Terminal Connection: Lug

• Temperature Rating: 104°F

• Wire Gauge: 12 to 3/0 AWG

• Actuator Type: Pivot/Toggle Handle

• Nema Rating: 1, 4, 12, 4X, 3R

• Interrupting Rating: 25kAIC@480V

• Size: 6.31"H x 4.12"W x 3.38"D

• Standards: CE, UL, HACR, RoHS
