New FAZ-C1.5/2-NA Eaton FAZ-C1.5/2-NA 2 Pole Circuit Breaker

Eaton FAZ-C1.5/2-NA 2 Pole Circuit Breaker

Specifications :

• Series: FAZ

• Amperage: 1.5

• Poles: 2

• Mounting Type: Din Rail

• MPN: FAZ-C1.5/2-NA

• Voltage: 277/480VAC, 96VDC

• Phase: 1

• Frame Type: FAZ

• Connection Type: Feed-Thru

• Functions: LI - Long Time and Instantaneous

• Protection: Thermal Magnetic

• Application: Generation - Renewable Energy - Alternative Energy - Other Generation - Conventional Energy Datacenters - IT Space: CI and Hyper Converged - Marine Vessels and Equipment

• Terminal Connection: Line and Load

• Temperature Rating: -40 to 75°C

• Wire Gauge: 18 to 6 AWG

• Actuator Type: Toggle

• Body Material: Nylon

• Interrupting Rating: 14kAIC, 10kAIC

• Size: 4.13"H x 2.97"W x 1.4"D

• Approval: UL, CSA, IEC, CE, VDE

• Standards: RoHS
