New HMCPS050K2C Eaton HMCPS050K2C 3 Pole Circuit Breaker

Eaton HMCPS050K2C 3 Pole Circuit Breaker

Specifications :

• Series: C

• Amperage: 50

• Poles: 3

• MPN: HMCPS050K2C

• Mounting Type: Din-Rail, Panel

• Voltage: 600VAC, 250VDC

• Phase: 3

• Frame Type: FD

• Connection Type: Feed-Thru

• Circuit Breaker Type: Standard

• For Use With: Electric Starters, Motor Starters Equipped with Electronic Overload Relays

• Application: Motor Drive and Control, Industrial, Defense, Military and Aerospace

• Functions: Long Time and Instantaneous Trip

• Protection: Thermal Magnetic

• Terminal Connection: Line and Load Side Lug

• Actuator Type: Toggle

• Temperature Rating: -4 to 158 °F

• Min Wire Size: 14 AWG

• Max Wire Size: 1/0 AWG

• Interrupting Rating: 65kAIC at 600VAC

• Size: 5"H x 5"W x 8"D

• Approval: UL, CSA, IEC
