New PDG21G0020TFFL Eaton PDG21G0020TFFL 1 Pole Circuit Breaker

Eaton PDG21G0020TFFL 1 Pole Circuit Breaker

Specifications :

• Series: PDG

• Amperage: 20

• Poles: 1

• MPN: PDG21G0020TFFL

• Voltage: 600VAC

• Phase: 1

• Frame Type: PDG

• Connection Type: Bolt-On

• Functions: LI - Long Time and Instantaneous Trip

• Protection: Thermal Magnetic

• Circuit Breaker Type: PD2 Global

• For Use With: Power Defense

• Application: Electrical Assemblies, Panels and EOEMs, Utility - Substations, Utility Transmission and Distribution, Vehicles - Vocational, Generation - Conventional Energy, Vehicles - On-Road, Mobile Machinery and Equipment, Aviation, Stationary Mach Equip in Factory - Robotics, Generation - Renewable Energy - Alternative Energy, Marine Vessels and Equipment

• Terminal Connection: Load Side

• Temperature Rating: -4 to 158 °F

• Min Wire Size: 14 AWG

• Max Wire Size: 1/0 AWG

• Interrupting Rating: 35kAIC at 480VAC

• Size: 2.2"H x 1.38"W x 3.5"D

• Approval: CSA, CCC, IEC, UL

• Standards: RoHS
