New CFD63B225 Siemens CFD63B225 3 Pole Circuit Breaker
Siemens CFD63B225 3 Pole Circuit Breaker
Specifications :
• Series: Sentron
• Amperage: 225
• Poles: 3
• UPC: 783643212206
• MPN: CFD63B225
• Voltage: 600VAC, 500VDC
• Phase: 3
• Frame Type: CFD
• Connection Type: Bolt-On
• Functions: Long Time and Instantaneous Trip
• Protection: Thermal Magnetic
• Application: Reverse Feed
• Terminal Connection: Line and Load Side Lug
• Temperature Rating: 40°C
• Wire Gauge: 6 AWG-350KCM (CU), 4 AWG-350KCM (AL)
• Interrupting Rating: 100kAIC at 600V, 200kAIC at 480V
• Size: 14.25"H x 4.5"W x 4"D
• Standards: UL, IEC, HACR, RoHS
