Eaton CN55GN3AB Contactor
Specifications :
• Series: Freedom
• Amperage: 45
• Poles: 3
• Mounting Type: Panel
• MPN: CN55GN3AB
• Voltage: 600VAC
• Phase: 1, 3
• Frame Type: CN55
• Connection Type: Screw
• Protection: Magnetic
• For Use With: Motor Control Systems
• Application: Commercial, Institutional Buildings, Structures
• Terminal Connection: Box Lug
• Temperature Rating: -5 to 65°C
• Action: Reversing
• Nema Size: 2
• Contact Configuration: 1 NO, 1 NC
• Coil Volts: 110VAC at 50Hz, 120VAC at 60Hz
• Operating Cycles: 3000000
• Size: 5.05"H x 2.56"W x 4.44"D
• Approval: UL, CSA
• Standards: RoHS
