New CVH3100X Eaton CVH3100X 3 Pole Circuit Breaker

Eaton CVH3100X 3 Pole Circuit Breaker

Specifications :

• Series: CVH

• Amperage: 100

• Poles: 3

• MPN: CVH3100X

• Voltage: 120/240VAC

• Phase: 3

• Frame Type: CVH

• Connection Type: Bolt-On

• Functions: Long Time and Instantaneous Trip

• Protection: Thermal Magnetic

• Application: Generation - Renewable Energy - Alternative Energy Generation - Conventional Energy Marine Vessels and Equipment - Other Data Centers - IT Space: CI and Hyper Converged Other

• Terminal Connection: Line and Load Side Lug

• Temperature Rating: 40°C

• Wire Gauge: #6 to 4/0 AWG CU/AL

• Interrupting Rating: 100kAIC@240V

• Size: 4.9"H x 4.9"W x 7.7"D

• Approval: UL, CSA
