Eaton HFD2225 2 Pole Circuit Breaker
Specifications :
• Series: C
• Amperage: 225
• Poles: 2
• Mounting Type: Panel
• MPN: HFD2225
• Voltage: 600VAC/250VDC
• Phase: 1
• Frame Type: FD
• Connection Type: Bolt-On
• Functions: Long Time and Instantaneous Trip
• Protection: Thermal Magnetic
• Application: Electrical Assemblies, Panels, EOEMs, Panelboard, Switchboard, Motor Control Center, and Busway
• Terminal Connection: Load Side Lug
• Temperature Rating: 40 °C
• Interrupting Rating: 100kAIC at 240VAC, 65kAIC at 480VAC
• Size: 2.75"H x 2.75"W x 3.38"D
• Approval: UL
