New TEYF120 General Electric TEYF120 1 Pole Circuit Breaker

General Electric TEYF120 1 Pole Circuit Breaker

Specifications :

• Series: TEY

• Amperage: 20

• Poles: 1

• MPN: TEYF120

• Voltage: 120/240/277/480VAC, 125VDC

• Phase: 1

• Frame Type: TEY

• Connection Type: Bolt-On

• Functions: Long Time and Instantaneous Trip

• Protection: Thermal Magnetic

• Circuit Breaker Type: Standard

• For Use With: GE Light Panels, Motor Control Centers and Panelboards

• Application: Residential, Commercial, Industrial

• Terminal Connection: Lug

• Temperature Rating: 40°C

• Actuator Type: Toggle

• Body Material: Plastic

• Min Wire Size: 14 AWG

• Max Wire Size: 10 AWG

• Interrupting Rating: 18kA at 277VAC

• Size: 5.2"H x 1.0"W x 2.94"D

• Standards: UL, CSA
