New TEYH1060B General Electric TEYH1060B 1 Pole Circuit Breaker
General Electric TEYH1060B 1 Pole Circuit Breaker
Specifications :
• Series: TEYH
• Amperage: 60
• Poles: 1
• MPN: TEYH1060B
• Voltage: 277/480VAC, 125VDC
• Phase: 1
• Frame Type: TEY
• Connection Type: Bolt-On
• Circuit Breaker Type: Standard
• Functions: Long Time and Instantaneous Trip
• Protection: Thermal Magnetic
• For Use With: Lighting Panels, Motor Control Centers and Panelboards
• Terminal Connection: Load Side Lug
• Temperature Rating: 40 °C
• Max Wire Size: 10 AWG
• Min Wire Size: 4 AWG
• Actuator Type: Toggle
• Interrupting Rating: 35kAIC at 480V
• Size: 5.2"H x 1"W x 3"D
• Approval: UL
